- Connection Technology:
- USB-C Alt Mode
- Driverless:
- Yes
- Additional Screen Outputs:
- 4
- Video Ports:
- DisplayPort, HDMI
- Maximum Resolution:
- 4K
- Power Delivery :
- 100W
- Operating System(s):
- Windows
- SD Card Reader:
- Yes
- Number of USB Ports:
- 10
- USB Fast Charging:
- Yes
- TAA Compliant:
-
- Docking Station Family:
- The Innovator
- DockWorks:
- Yes (for Windows only)
- Best For:
- USB-C Laptops & Ultrabooks that support Power Delivery and Monitors that support up to quad 4K
- Compatibility:
- Windows 10 or above
- Card Reader:
- SD Cards and Micro SD card slots (UHS-II, SD4.0)
- Features:
- EQ
- USB-A Ports:
- 6 x: USB 3.2 Gen2 (two front, four back) with 5V/0.9A
- USB-C Ports:
- 4 x USB-C 3.2 Gen2 (two front, two back) with one 30W(15V/2A) and three 15W(5V/3A) charging
- Audio:
- 1 x 3.5mm Combo Microphone & Headphone Port (front)
- Data Transfer Speeds:
- Supports up to 10Gbps data transfer speed
- Ethernet Speed (Mbps):
- 1000 Actual Ethernet speeds may vary depending on, but not limited to, Internet bandwidth, Ethernet cables, network switches, and the hardware and firmware performance of the host computer., 10, 100
- Maximum Resolution Supported:
- Maximum Resolution (DP1.4/HBR3 with DSC On): Single 8K at 30Hz, Quad 4K at 30Hz. Typical Resolution (DP1.4/HBR3): Single 4K at 60Hz, Quad 1080p at 30Hz.
- Warranty:
- Limited 3-year warranty
- Plug & Play:
- Plug & Play installation without need for drivers or downloads
- System Requirements:
- Host device must support Power Delivery and DisplayPort Alt Mode over USB-C
- USB-C Power Delivery:
- Supports USB-C PD 3.0 (100W of laptop charging)
- Video Output:
- 2 x DisplayPort v1.4, 2 x HDMI v2.1
- 4K Support:
- Yes
